WMZS2C01 EATON

WMZS2C01 EATON Processor module

Brand：EATON Model number：WMZS2C01

Country of origin: the States Product weight：0.55kg

HS code：8538900000

Product Details：

Product Dimensions：

An Eaton Processor Module is the central processing unit within an Eaton control system, such as a Programmable Logic Controller (PLC) or a Human-Machine Interface (HMI) with integrated control capabilities. It's the brain of the system, responsible for executing control logic, performing calculations, managing communication, and coordinating the activities of other modules like I/O and communication interfaces.

Product Details

Functionality:

Executes user-defined control programs.
Manages data acquisition from input modules.
Controls output modules based on the program logic.
Handles communication with other devices and systems.
Often provides real-time clock functionality for time-stamped data and scheduling.

Types (vary depending on the Eaton control system):

PLC CPUs: Designed for robust industrial control, offering various processing power levels, memory capacities, and communication interfaces. Examples include the CPUs for the Eaton XC series PLCs.
HMI/PLC Integrated Units: Combine visualization and control functionalities in a single module. These often have a processor responsible for both running the HMI application and executing control logic. Examples include certain Eaton XV series HMI/PLCs.

Key Features (can include):

High-performance processors (e.g., ARM Cortex).
Ample program and data memory.
Integrated communication interfaces (Ethernet, CAN, serial).
Real-time operating systems (RTOS) for deterministic control.
Support for various programming languages (e.g., IEC 61131-3).
Secure communication protocols and cybersecurity features in some models.
Compact and rugged design for industrial environments.

Product Parameters

Processor Type and Speed: Specifies the type of processor (e.g., ARM Cortex A7) and its clock speed (e.g., 800 MHz, 1 GHz), which influences processing power.
Program Memory: The amount of memory available for storing the user's control program (e.g., Flash memory, often measured in MB or GB).
Data Memory (RAM): The amount of volatile memory used for storing runtime data, variables, and buffers (e.g., measured in MB).
Retain Memory (NVRAM): Non-volatile memory used to store critical data that needs to be preserved during power loss (e.g., measured in KB or MB).
Communication Interfaces: The types and number of built-in communication ports (e.g., Ethernet (number of ports, speed), RS-232, RS-485, CAN, USB).
Real-Time Clock (RTC): Whether an integrated RTC is present and if it has battery or capacitor backup.
Scan Cycle Time: The time it takes for the processor to execute the control program once (measured in milliseconds or microseconds).
Number of Expandable I/O Modules: The maximum number of I/O modules the processor can support.
Operating Temperature: The range of ambient temperatures in which the module can operate reliably.
Power Supply: The required input voltage (e.g., 24V DC).
Certifications: Compliance with relevant industrial standards (e.g., UL, CE).

Product Advantages

High Performance: Powerful processors enable fast execution of complex control algorithms.
Reliability: Designed for continuous operation in industrial environments.
Connectivity: Integrated communication interfaces facilitate seamless integration with other devices and networks.
Flexibility and Scalability: Compatibility with Eaton's modular I/O systems allows for easy expansion and customization of control systems.
Advanced Features: Some modules offer features like integrated web servers, OPC UA support, and cybersecurity functionalities for modern automation requirements.
Support for Industry Standards: Compliance with IEC 61131-3 programming languages and common communication protocols ensures interoperability.
Compact Design: Often designed to be space-efficient for installation in control cabinets.

Important Considerations

Application Complexity: Choose a processor module with sufficient processing power and memory for the intended application.
Number of I/O Points: Select a processor that can handle the required number of input and output signals.
Communication Requirements: Ensure the module has the necessary communication interfaces and supports the required protocols for network integration.
Environmental Conditions: Verify that the operating temperature range and environmental protection (IP rating if applicable) are suitable for the installation location.
Software Compatibility: Ensure compatibility with the programming software (e.g., CODESYS) and any other required software tools.
Power Requirements: Provide a stable and adequate power supply according to the module's specifications.
Firmware Updates: Keep the processor module's firmware updated for optimal performance and security.
Proper Grounding: Ensure correct grounding to prevent electrical noise and ensure safe operation.

Product Applications

Eaton Processor Modules are used in a wide range of industrial and automation applications, including:

Machine Control: Controlling the operation of individual machines in manufacturing processes.
Process Automation: Managing complex industrial processes in sectors like chemical, oil & gas, and food & beverage.
Robotics: Coordinating the movements and actions of industrial robots.
Material Handling: Controlling conveyors, sorting systems, and automated storage and retrieval systems.
Building Automation: Managing HVAC, lighting, and security systems in commercial buildings.
Energy Management: Controlling and monitoring energy generation and distribution systems.
Infrastructure: Controlling equipment in water treatment plants, transportation systems, and power grids.

EHD1020 EATON

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
