C25DND230B EATON

C25DND230B EATON Digital Input Module

Brand：EATON Model number：C25DND230B

Country of origin: the States Product weight：0.55kg

HS code：8538900000

Product Details：

Product Dimensions：

Eaton Digital Input Modules are essential components in industrial automation systems, designed to receive and process digital signals from field devices such as switches, pushbuttons, sensors (e.g., proximity, limit), and other discrete signal sources. These modules act as the interface between the physical world and the control system (like a PLC or PAC), converting on/off signals into a format that the controller can understand and act upon.

Product Details

Functionality:

They detect the state (on or off, high or low) of connected digital input devices.
They provide signal conditioning to ensure reliable signal transmission to the control system. This may include filtering, debouncing, and voltage level shifting.
Many modules offer electrical isolation to protect the control system from voltage spikes and noise from the field.

Types:

Voltage Range: Supporting different input voltage levels (e.g., 24V DC, 120V AC).
Number of Channels: Providing different densities of input points (e.g., 8, 16, 32 channels per module).
Input Type: Supporting different wiring configurations (e.g., sinking, sourcing).
Speed: Some modules are designed for high-speed signal acquisition.
Communication Interface: Integrating with different I/O bus systems and communication protocols.
Eaton offers various digital input modules differentiated by:

Key Features:

Rugged design for industrial environments, capable of withstanding vibration, shock, and temperature variations.
LED indicators to visually display the status of each input channel.
Often include removable terminal blocks for easy wiring and maintenance.
Diagnostic capabilities to aid in troubleshooting.
Compliance with relevant industrial safety standards and certifications.

Product Parameters

Input Voltage Range: Specifies the acceptable voltage levels for the input signals (e.g., 24V DC nominal, with a range of 19.2 to 30V DC).
Input Current: The current drawn by the input circuit when the input is active.
Number of Channels: The number of individual digital input points available on the module.
Input Type (Sinking/Sourcing): Defines how the input device is wired and how current flows in the input circuit.
Response Time: The time delay between a change in the input signal and its detection by the module.
Isolation Voltage: The level of electrical isolation provided between the field side and the system side.
Operating Temperature: The ambient temperature range within which the module can operate reliably.
Storage Temperature: The temperature range for storing the module when not in use.
Humidity: The acceptable relative humidity range for operation and storage.
Power Consumption: The amount of power drawn by the module itself.
Dimensions and Mounting: Physical size and the method for mounting (typically DIN rail).
Certifications: UL, CE, and other relevant industry approvals.

Product Advantages

Reliable Signal Acquisition: Designed to accurately and consistently detect digital signals from field devices.
Noise Immunity: Incorporates features to minimize the impact of electrical noise and interference commonly found in industrial environments.
System Protection: Often provides electrical isolation to safeguard the control system from field-side faults.
Easy Installation and Wiring: Typically features user-friendly terminal blocks and clear labeling.
Status Indication: LEDs provide a quick visual indication of the state of each input, simplifying diagnostics.
Scalability: Available in various channel densities to match different application requirements.
Integration: Seamlessly integrates with Eaton's and other compatible control systems.

Important Considerations

Voltage Compatibility: Ensure that the input voltage range of the module matches the output voltage of the field devices being connected.
Current Limitations: Verify that the input current requirements of the field devices are within the specifications of the input channels.
Wiring Type (Sinking/Sourcing): Select modules with the appropriate input type to match the wiring configuration of the sensors and switches. Incorrect wiring can damage the module or prevent proper operation.
Environmental Conditions: Ensure that the operating environment (temperature, humidity, vibration) is within the module's specifications.
Isolation Requirements: Consider the need for electrical isolation based on the application and potential for voltage differences or noise.
Response Time: For high-speed applications, choose modules with a sufficiently fast response time.
Proper Grounding: Follow recommended grounding practices to minimize noise and ensure safety.
Adherence to Wiring Diagrams: Always refer to the manufacturer's wiring diagrams for correct connections.

Product Applications

Monitoring Discrete Sensors: Detecting the state of limit switches, proximity sensors, photoelectric sensors, and other on/off sensors.
Reading Switch and Pushbutton Status: Interfacing with operator controls and feedback signals from mechanical switches.
Receiving Digital Outputs from Other Devices: Accepting digital signals from encoders, safety relays, and other control components.
Counting Events: Some digital input modules have high-speed counting capabilities for applications like material handling and packaging.
Position Detection: Monitoring the position of actuators and other moving parts through discrete position sensors.
Safety Systems: Used in safety circuits to monitor the status of safety interlocks, emergency stop buttons, and safety light curtains.
Packaging Machinery: Detecting the presence or position of products and machine components.
Conveyor Systems: Monitoring the status of belt movement, jams, and diverter positions.
General Machine Automation: Providing the control system with discrete feedback from various parts of a machine.

MTL5531 EATON

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
