860830 EATON

860830 EATON analog module

Brand：EATON Model number：860830

Country of origin: the States Product weight：0.55kg

HS code：8538900000

Product Details：

Product Dimensions：

Eaton analog modules are essential components in industrial automation systems, designed to interface with analog signals from sensors and control analog output devices. These modules translate real-world analog values into digital data for control systems and vice versa.

Product Details

Functionality:

Analog input modules receive continuous electrical signals (voltage or current) from sensors that measure physical quantities like temperature, pressure, flow, or level.
Analog output modules generate continuous electrical signals to control actuators such as valves, motors, and positioners.
They provide signal conditioning, isolation, and accurate conversion between analog and digital domains.

Types:

Analog Input Modules (Voltage, Current, Thermocouple, RTD)
Analog Output Modules (Voltage, Current)
Combination Analog I/O Modules
Eaton offers various analog modules, including:

Key Features:

High accuracy and resolution for precise measurement and control.
Galvanic isolation to protect the control system from electrical noise and ground loops.
Configurable input/output ranges to accommodate various sensor and actuator types.
Advanced diagnostic capabilities for troubleshooting and maintenance.
Compatibility with various industrial communication protocols.

Product Parameters

Input/Output Ranges:

Voltage (e.g., 0-10V, ±10V)
Current (e.g., 4-20mA, 0-20mA)
Temperature (Thermocouple types, RTD types)

Resolution:

12-bit, 16-bit, or higher for accurate conversion.

Accuracy:

Specified as a percentage of full-scale range.

Isolation Voltage:

The maximum voltage the module can withstand between the field side and the system side.

Communication Interface:

Ethernet/IP, Modbus TCP, Profibus, etc.

Operating Temperature:

Industrial temperature range.

Power Supply:

Voltage and current requirements for the module.

Product Advantages

Precision:

High accuracy and resolution ensure precise control of analog processes.

Reliability:

Robust design and isolation features contribute to reliable operation in harsh industrial environments.

Flexibility:

Configurable input/output ranges and communication options provide flexibility for various applications.

Diagnostic Capabilities:

Advanced diagnostics simplify troubleshooting and maintenance.

Compatibility:

Designed to integrate seamlessly with Eaton and other manufacturers' control systems.

Important Considerations

Signal Type and Range:

Select modules that match the specific signal types and ranges of the sensors and actuators.

Resolution and Accuracy:

Choose modules with sufficient resolution and accuracy for the application's precision requirements.

Isolation:

Ensure adequate isolation to protect the control system from electrical noise and ground loops.

Environmental Conditions:

Verify that the modules can withstand the operating temperature and humidity of the application environment.

Wiring and Installation:

Follow proper wiring and installation guidelines to ensure safe and reliable operation.

Product Applications

Process Control:

Controlling temperature, pressure, flow, and level in industrial processes.

Manufacturing:

Monitoring and controlling machine parameters.

Building Automation:

HVAC control, energy management.

Water and Wastewater Treatment:

Monitoring and controlling water treatment processes.

Energy Management:

Monitoring and controlling power generation and distribution.

434541-1 EATON

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
