1775KTPMPP 1700 92-01940-02 Cutler-Hammer

1775KTPMPP 1700 92-01940-02 Cutler-Hammer Motor Circuit Breaker

Brand：Cutler-Hammer Model number：1775KTPMPP 1700 92-01940-02

Country of origin: United States Product weight：0.55kg

HS code：8517623990

Inquire Now

Product Details：

Product Dimensions：

The 1775KTPMPP is a tactile interface module designed to integrate with the 1700 series of industrial monitors or control terminals. It serves as the primary input method for operators to monitor system status, acknowledge alarms, and input setpoints into the automation system. The unit is constructed with high-durability materials to withstand chemical exposure, dust, and repetitive mechanical strikes common in factory settings. The internal circuitry, identified by the 92-01940-02 board number, manages the scanning of key matrix inputs and ensures fast response times for real-time control.

Product Parameters

The technical specifications of the 1775KTPMPP 1700 focus on its physical durability and electrical compatibility with the host system:

Part Number Identification: Primary model 1775KTPMPP, Sub-assembly 92-01940-02.
Compatibility: Exclusively designed for the Cutler-Hammer 1700 Series Industrial Terminals.
Input Type: Membrane-style tactile keys with embossed mechanical feedback.
Communication Interface: Ribbon cable or multi-pin connector for direct attachment to the main logic board.
Environmental Sealing: Typically meets NEMA 4/4X and IP65 standards when correctly installed in a matching enclosure.
Electrical Rating: Low voltage DC input, typically $5 \text{ V}$ or $12 \text{ V}$ logic levels provided by the terminal backplane.
Operating Temperature: Rated for industrial ranges from $0\text{°C}$ to $55\text{°C}$ .
Key Lifecycle: Rated for millions of actuations per key.

Product Advantages

One of the key advantages of this unit is its Industrial Hardening. Unlike consumer-grade touchscreens, this membrane keypad is resistant to oils, grease, and many industrial solvents, making it ideal for the "dirty" side of manufacturing. The Tactile Feedback allows operators wearing gloves to feel a positive "click" when a command is entered, reducing input errors in high-pressure environments. Because it is a Direct Replacement Part, it allows facilities to maintain older, reliable 1700 series systems without the massive expense of a full system migration to modern touch panels. Furthermore, the High-Contrast Design of the legends ensures that key functions remain visible even in low-light factory conditions.

Important Considerations and Precautions

When handling or installing the 1775KTPMPP 1700, specific precautions are necessary to avoid damaging the unit. Electrostatic Discharge (ESD) is a significant risk; always use a grounded wrist strap when connecting the 92-01940-02 board to the main terminal logic. During installation, the Adhesive Gasket must be perfectly clean and free of debris to ensure a NEMA 4 watertight seal. Avoid using sharp tools like screwdrivers to press the keys, as this can puncture the membrane and lead to internal short circuits. Finally, ensure the Ribbon Cable is seated squarely in the connector; a slanted insertion can cause intermittent "ghost" keypresses or complete communication failure.

Product Applications

The Cutler-Hammer 1775KTPMPP 1700 is primarily used in sectors where legacy control systems remain the backbone of production.

Motor Control Centers (MCC): Providing a local interface for starting, stopping, and monitoring large industrial motors.
Power Distribution Monitoring: Used in switchgear assemblies to view voltage, current, and frequency data on the 1700 series display.
Metal Processing: Installed on CNC or milling machines where metal shavings and coolant would destroy a standard keyboard.
Food and Beverage: Utilized in wash-down areas where the equipment is regularly sprayed with cleaning agents.
Material Handling: Integrated into conveyor control stations to manage sorting and routing logic via the keypad.
