3500/53-03-0 Bently Nevada

3500/53-03-0 Bently Nevada Interface Module

Brand：BENTLY NEVADA Model number：3500/53-03-0

Country of origin: U.S. Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

Bently Nevada Interface Modules are specialized electronic devices designed to act as intermediaries within the 3500 Series system. They ensure seamless communication and data flow between the monitoring rack (which houses the individual monitor modules for vibration, temperature, etc.), external software applications (like System 1), and other hardware components.

Functionality: These modules enable the configuration of the 3500 rack, retrieve vital machinery information, and facilitate the transfer of both steady-state and transient dynamic data (including waveforms) to host software for analysis and diagnostics. They do not typically form part of the critical monitoring path for machinery protection trips, but are essential for data availability and system management.
Key Types:

Rack Interface Module (RIM): This is the primary point of connection to the 3500 rack. It supports a proprietary protocol for rack configuration and retrieving basic machinery data. A Triple Modular Redundant (TMR) version of the RIM is available for TMR system configurations, which also performs "monitor channel comparison" to ensure the integrity of redundant monitor outputs.
Transient Data Interface (TDI) Module: This module combines the functions of a RIM with advanced data collection capabilities. It continuously collects steady-state and transient dynamic (waveform) data from the 3500 M-series monitors and transmits it via Ethernet to the System 1 condition monitoring and diagnostic software. The TDI is crucial for detailed machinery diagnostics, especially during startups, shutdowns, or unusual events.
Display Interface Module: This module facilitates communication between the 3500 monitoring system and local display units, allowing operators to view real-time data and alarm statuses directly at the rack.
Accelerometer Interface Module (AIM): While typically considered an I/O module, some specific accelerometer interface modules are distinct in their function of converting raw accelerometer signals into a format usable by the 3500 monitors.

Common Features:

Proprietary Protocol Support: Utilizes Bently Nevada's specific protocols for secure and efficient communication within the 3500 system.
Ethernet Connectivity: Modern interface modules often include Ethernet ports for high-speed data transfer to host software.
Diagnostic LEDs: Visual indicators for module status, power, and communication activity.
Robust Design: Engineered for reliable operation in industrial environments.

Product Parameters

Specific parameters vary by module model, but common specifications include:

Power Consumption: Typically low, e.g., 10.5 Watts for a 3500/22M TDI.
Communication Interfaces: Ethernet (10Base-T/100Base-TX autosensing, sometimes Fiber-Optic 100Base-FX), RS-232, RS-485.
Data Types Supported: Steady-state data, transient dynamic (waveform) data, alarm states, system event lists.
Data Collection Capabilities (for TDI): Number of dynamic data channels supported (may require enabling disk).
Operating Temperature: Wide industrial range, typically -30°C to +65°C (-22°F to +149°F).
Storage Temperature: -40°C to +85°C (-40°F to +185°F).
Humidity: Up to 95%, non-condensing.
Dimensions and Weight: Standardized to fit within the 3500 rack chassis. For example, a 3500/22M TDI is approximately 241.3 mm x 24.4 mm x 241.8 mm (9.50 in x 0.96 in x 9.52 in) and weighs around 0.91 kg (2.0 lbs).
Rack Slot Requirement: Typically occupies a single full-height front slot (e.g., Slot 1, adjacent to power supplies).
Approvals: Often carry approvals like Class 1, Div 2 for hazardous locations (e.g., ATEX, North American certifications).

Product Advantages

Seamless Integration: Designed for seamless integration within the Bently Nevada 3500 Series Monitoring System, ensuring cohesive data flow.
Enhanced Diagnostics: Enables the capture of critical transient data (e.g., during startups/shutdowns) for advanced machinery health diagnostics using System 1 software.
System Configuration and Management: Provides the primary interface for configuring the 3500 rack and retrieving essential system information.
High Reliability and Stability: Inherits the robust design and field-proven reliability characteristic of Bently Nevada products, ensuring continuous operation in harsh industrial environments.
Scalability: The modular nature of the 3500 system allows for flexible configuration and expansion by adding relevant interface and monitoring modules.
Redundancy Options: TMR versions of interface modules (like the RIM and TDI) provide enhanced system reliability and fault tolerance for critical applications.

Important Considerations

Proper Slot Placement: Interface modules like the RIM and TDI must be installed in specific slots (typically Slot 1) within the 3500 rack for proper operation.
Not Part of Critical Monitoring Path: While essential for data and configuration, most interface modules do not directly impact the critical machinery protection trip path. However, a failure could affect data collection or configuration capabilities.
Static Electricity Precautions: Circuit boards are sensitive to electrostatic discharge (ESD). Always follow proper grounding procedures (e.g., using a grounding strap) when handling these modules to prevent damage.
Environmental Limits: Ensure the operating and storage environmental conditions (temperature, humidity) are within the module's specified limits.
Firmware and Software Compatibility: Ensure the firmware version of the interface module is compatible with the version of the 3500 System Configuration software and System 1 condition monitoring software being used.
Wiring Recommendations: Adhere to all Bently Nevada wiring recommendations for power, communication, and I/O connections to ensure optimal performance and safety.

Product Applications

Bently Nevada Interface Modules are indispensable in various industries that rely on continuous machinery monitoring and protection:

Power Generation:

Monitoring turbines (gas, steam, hydro) and generators.
Ensuring the health of auxiliary equipment like pumps, fans, and compressors.

Oil & Gas:

Critical for condition monitoring of compressors, pumps, and turbines in upstream, midstream, and downstream operations.
Used in refineries, petrochemical plants, and LNG facilities.

Process Industries:

Monitoring large rotating machinery in chemical plants, paper mills, and other continuous process facilities.

Manufacturing:

Protecting high-speed rotating equipment in large-scale manufacturing operations.

Water and Wastewater Treatment:

Monitoring large pumps, blowers, and mixers for vibration and health.

3500/53-03-0 Bently Nevada

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
