3300-05-24-00-00 BENTLY

3300-05-24-00-00 Bently Nevada Termination Unit

Brand：BENTLY NEVADA Model number：3300-05-24-00-00

Country of origin: U.S. Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

A Bently Nevada Termination Unit, often called a Termination Block or a Terminal Block, is a critical component within a Bently Nevada machinery protection and condition monitoring system. These units serve as the physical interface between the field wiring from sensors (probes, transducers) and the internal electronics of the monitoring system (such as the 3500 series rack). They are designed to simplify wiring, provide isolation, and ensure a secure, organized connection, which is essential for the reliability and accuracy of the monitoring signals. Termination units are passive devices that organize and connect the field wiring to the appropriate monitor module within the system rack.

Product Parameters

Specific parameters vary by the type of unit and its intended application, but common specifications include:

Connector Type: Typically available in two main styles: terminal strip or Euro-style connectors, which offer different wiring and installation preferences.
Input Types: Designed to handle specific signal types from Bently Nevada transducers, including Proximitor, seismic, Keyphasor, and various position transducers like Rotary Potentiometer (RPT) or DC LVDT.
Channel Density: Varies based on the number of sensors it can connect to a single monitor module. For example, some units are designed for dual-channel monitoring modules.
Physical Dimensions: These are application-specific and designed to fit into standard control cabinets or DIN rails, with specific lengths, widths, and heights to accommodate different wiring needs.
Operating and Storage Temperature: Standard industrial ranges, typically designed to operate reliably in environments from -40°C to +85°C.
Certifications: Often certified to meet international standards such as CE, CSA, and UL for use in hazardous areas.

Product Advantages

Simplified Installation and Wiring: Termination units provide a clean and organized method for connecting field wiring to the monitoring system, significantly reducing installation time and the potential for wiring errors.
Enhanced Reliability: By providing a single point of connection, they reduce the number of potential failure points and help maintain signal integrity from the sensor to the monitor.
Improved Maintainability: The organized terminal blocks make it easier and safer for technicians to troubleshoot and perform maintenance without disturbing other connections in the system.
System Integrity: They help to maintain the electrical isolation between the field wiring and the sensitive electronics of the monitoring system, protecting the monitor modules from electrical noise and surges.
Versatility: Bently Nevada offers a variety of termination units to match different sensor types and monitoring modules, allowing for flexible system configurations.

Important Considerations

Compatibility: Always ensure the termination unit is compatible with the specific Bently Nevada monitor module and sensor type you are using. Mismatched components can lead to incorrect readings or system failure.
Wiring Standards: Proper wiring is crucial. Follow all installation instructions, using correct wire gauge, torque specifications, and grounding procedures to ensure a safe and reliable connection.
Environmental Conditions: While rugged, the units should be installed in an environment that meets their specified temperature, humidity, and IP (Ingress Protection) ratings.
Physical Location: The physical location of the termination unit should be planned to minimize cable length and exposure to electrical interference.
