6200P-NS3C1 Allen-Bradley

6200P-NS3C1 Allen-Bradley Power Board

Brand：Allen-Bradley Model number：6200P-NS3C1

Country of origin: United States Product weight：0.55kg

HS code：8517623990

Inquire Now

Product Details：

Product Dimensions：

The 6200P-NS3C1 serves as a dedicated industrial workstation that runs standard Windows-based operating systems. Unlike integrated panel PCs, this unit is a "Non-Display" (NS) version, meaning it is intended to be paired with a separate industrial monitor or used as a headless controller. It features an industrial-grade motherboard and components designed to handle the vibration, dust, and temperature fluctuations common in factory floor environments. The "3C1" configuration indicates a specific set of hardware specifications, including the processor type, memory capacity, and storage options tailored for mid-to-high level automation tasks.

Product Parameters

The technical profile of the 6200P-NS3C1 is centered on industrial durability and standard connectivity.

Processor: Typically equipped with an Intel Celeron or Pentium M processor, optimized for thermal efficiency and consistent performance.
Memory: Standard configuration usually includes 512 MB to 1 GB of RAM, expandable depending on the specific motherboard revision.
Storage: Features a high-capacity hard disk drive (HDD) or a solid-state option for system and data storage.
Operating System: Usually pre-installed with Windows XP Professional or Windows 2000, designed to support legacy industrial software.
Connectivity Ports: Includes multiple RS-232 serial ports, a parallel port, USB 2.0 ports, and dual Ethernet ports for network redundancy or separation of office and plant networks.
Video Output: Standard VGA port for connecting to external CRT or LCD industrial monitors.
Expansion: Contains PCI expansion slots allowing for the addition of specialized communication cards (such as ControlNet or DeviceNet cards).
Power Supply: Designed for AC input, typically ranging from 90V to 264V AC at 47-63 Hz.

Product Advantages

One of the primary advantages of the 6200P-NS3C1 is its Rugged Construction. Unlike commercial-grade PCs, this unit uses vibration-dampening mounts for the hard drive and a heavy-duty chassis to prevent internal damage. The Compact Design allows it to be DIN-rail or wall-mounted inside a control cabinet, saving valuable floor space.

Another benefit is its Industrial Connectivity, providing native serial and parallel ports that are often missing from modern consumer laptops but remain essential for communicating with older PLC hardware. Furthermore, the Seamless Integration with the Rockwell Automation ecosystem ensures that software like FactoryTalk View or RSLogix runs efficiently with minimal driver conflicts. Its thermal management system is also superior, utilizing filtered cooling to prevent internal overheating without drawing in excessive metallic dust.

Important Considerations and Precautions

When deploying the 6200P-NS3C1, several safety and maintenance guidelines should be followed. First, Environmental Protection is key; while the unit is rugged, it should still be installed in an enclosure that meets the appropriate NEMA or IP rating for the specific environment (e.g., protecting against oil mist or hose-down cleaning).

Second, Proper Shutdown procedures must be followed. Because this unit often uses traditional spinning HDDs, sudden loss of power can lead to corrupted system files or mechanical drive failure. It is highly recommended to use an Uninterruptible Power Supply (UPS). Third, Ventilation is critical. Ensure that the cooling fans and filters are checked periodically; a clogged filter can lead to thermal throttling or system crashes. Finally, regarding Legacy Support, users should be aware that the hardware and pre-installed operating systems are reaching end-of-life status, and finding replacement parts or software updates may require sourcing through specialized industrial surplus or migration to the newer VersaView 5000 or 6000 series.

Product Applications

The 6200P-NS3C1 is utilized across a broad spectrum of industrial sectors where localized data processing is required.

Human Machine Interface (HMI) Servers: Acting as the central data collector and server for multiple thin-client terminals across a factory floor.
Data Logging and Historian: Running localized SQL databases or historian software to track production metrics and quality control data in real-time.
Automotive Assembly: Controlling complex robotic cells where the computer must process high volumes of I/O data and interface with vision systems for parts inspection.
Food and Beverage: Managing batch processing recipes and monitoring sterilization temperatures where the computer is safely tucked away in a remote control room or stainless steel cabinet.
Material Handling: Serving as the primary controller for high-speed sorting systems and automated storage and retrieval systems (AS/RS).
