2711P-K4M5D Allen-Bradley

2711P-K4M5D Allen-Bradley Central control module

Brand：Allen-Bradley Model number：2711P-K4M5D

Country of origin: United States Product weight：0.55kg

HS code：8517623990

Product Details：

Product Dimensions：

The Allen-Bradley 2711P-K4M5D is a Human Machine Interface (HMI) terminal from the PanelView Plus 600 family of products. It is designed to provide operators with a graphical interface to monitor and control industrial automation processes, specifically working within the Rockwell Automation Integrated Architecture.

Product Specifications

Product Type: Operator Interface Terminal
Family: PanelView Plus 600 (PV+ 600)
Catalog Number: 2711P-K4M5D
Display Type: Monochrome (Black and White)
Display Size: 5.7 inches diagonal
Resolution: $320 \times 240$ pixels (QVGA)
Input Type: Keypad (The "K" in the catalog number indicates Keypad)
Keypad Features: Includes system keys (e.g., F1-F10, navigation arrows, Enter, Exit) for direct control.
Communication Port: Ethernet (The "M" in the catalog number indicates an Ethernet port)
Operating System: Microsoft Windows CE
Application Software: FactoryTalk View Machine Edition (ME)
Input Power: $18 \text{ to } 32 \text{ VDC}$ (The "5D" at the end of the catalog number indicates DC Power)
Processor: $400 \text{ MHz}$ processor
Memory: $128 \text{ MB}$ RAM, $128 \text{ MB}$ non-volatile storage

Product Advantages

Integrated Architecture Compatibility: Offers seamless connectivity and high-speed data access to ControlLogix and CompactLogix PACs using EtherNet/IP, simplifying system design and reducing configuration time.
Robust Design: Built for harsh industrial environments, the PanelView Plus 600 terminals feature a rugged enclosure and are rated for reliable operation in typical factory floor conditions.
Non-Volatile Storage: Includes ample non-volatile storage for application files and system settings, ensuring data retention even after a power loss.
Enhanced Performance: Compared to legacy PanelView products, the PanelView Plus 600 features faster screen refresh rates and project loading times, improving operator efficiency.
Keypad Control: The physical keypad provides tactile feedback, which is crucial for applications where operators may be wearing gloves or need precise, instantaneous control without looking at the screen.

Important Considerations (Precautions)

Discontinued Status: The PanelView Plus 600 series, including the 2711P-K4M5D, is considered a legacy product and has been officially discontinued. Users should consider migrating to the newer PanelView Plus 7 or PanelView 5000 platforms for new applications.
Monochrome Display: This specific model uses a monochrome (black and white) display, which is a limitation compared to modern color HMIs. It may not be suitable for applications requiring complex color-coded graphics or high-definition visualization.
Power Supply Quality: Since it is a DC-powered unit, use a reliable, regulated $24 \text{ VDC}$ power supply that meets the specified voltage and current requirements to prevent unexpected shutdowns or component damage.
Firmware and Software: Ensure that the terminal's firmware and the FactoryTalk View ME application are compatible with the specific version of the ControlLogix/CompactLogix controller firmware being used to avoid communication issues.

Product Applications

The 2711P-K4M5D terminal is typically deployed on the factory floor for a wide range of control and monitoring tasks in industrial environments.

Small Machine Control: Providing local control and diagnostics for individual machines, such as pumps, fans, small conveyor systems, and packaging equipment.
Operator Data Entry: Allowing operators to enter setpoints, change recipes, and acknowledge alarms directly via the keypad.
Process Visualization: Displaying simple, real-time process graphics, status indicators, and trend data to monitor machine health and production status.
Alarm Management: Announcing and tracking system alarms, enabling operators to quickly identify and respond to faults and abnormal conditions.
Data Collection: Interfacing with the controller to log production metrics, cycle counts, and downtime reasons for analysis.
