1771-WI Allen-Bradley

1771-WI Allen-Bradley Power Board

Brand：Allen-Bradley Model number：1771-WI

Country of origin: United States Product weight：0.55kg

HS code：8517623990

Inquire Now

Product Details：

Product Dimensions：

The 1771-WI is a single-slot module that resides in a standard Allen-Bradley 1771 I/O chassis. It acts as a high-precision, low-level signal conditioner and digitizer. The module provides excitation voltage to the strain gauge load cells, reads the millivolt-level response signal, and converts this analog input into a digital weight value that the PLC-5 processor can use in its control logic via block transfer reads and writes. It features hardware calibration adjustments and onboard filtering to handle mechanical vibrations commonly found in industrial weighing applications.

Product Parameters

Module Type: Weight Instrument/Scale Input Module
Chassis Compatibility: 1771 Universal I/O Chassis
Backplane Current Load: Approximately $1.5 \text{ A}$ at $5 \text{ VDC}$
Load Cell Excitation Voltage: Typically delivers $10 \text{ VDC}$ excitation power to the load cells
Signal Input Range: Engineered for millivolt-per-volt ( $mV/V$ ) strain gauge outputs, typically supporting $\pm 20 \text{ mV}$ or $\pm 30 \text{ mV}$ full scale
Resolution: High-resolution Analog-to-Digital Converter (ADC), often providing up to $14$ -bit or $16$ -bit internal resolution for precision measurements
Isolation: Optically isolated input channels to shield the backplane logic from external field electrical noise
Connection Type: Uses a 1771-WG or 1771-WH wiring arm for tool-less removal of the module without disturbing the load cell cables

Product Advantages

A primary advantage of the 1771-WI is its Direct PLC Integration. By placing the weigh scale interface directly on the PLC rack, it eliminates the need for external weight transmitters and serial communication links, which drastically decreases data transmission latency. The module offers High-Speed Block Transfer, enabling the weight data to be updated in the processor memory every few milliseconds, making it suitable for high-speed filling operations.

Its Robust Filtering Options can be tuned to eliminate the mechanical vibration noise caused by agitators or plant machinery, ensuring a stable and true weight reading. Additionally, the Modular Hardware Design utilizing the 1771 wiring arm allows for rapid maintenance and module replacement, which minimizes system downtime.

Important Considerations and Precautions

When configuring the 1771-WI, Load Cell Calibration is paramount; the module must be calibrated using known certified test weights during commissioning to establish accurate zero and span references. Because this module deals with microvolt-level signals, Shielding and Noise Mitigation are critical. Load cell cables must be twisted-pair, shielded, and routed far away from high-voltage motor lines or variable frequency drives (VFDs) to prevent signal drifting.

Users must adhere to the Excitation Current Limits; overloading the module by connecting too many load cells in parallel can cause the internal excitation power supply to overheat and shut down. Given that the 1771 platform is a Legacy System, procurement of replacement parts can be difficult, so it is highly recommended to maintain a verified spare or plan for an eventual migration to newer platforms like ControlLogix. Finally, always Turn Off Chassis Power before inserting or removing the module to avoid damage to the backplane connectors.

Product Applications

The Allen-Bradley 1771-WI is implemented in automated environments where bulk weight measurements dictate process control.

Batching and Blending: Controlling the sequential addition of raw materials into mixing vessels based on target weight values in chemical and food production.
Silo and Tank Level Monitoring: Providing continuous weight-based inventory monitoring for large storage vessels containing powders, liquids, or grains.
Bagging and Filling Machines: Managing high-speed packaging lines where precise target weights must be achieved quickly to prevent product giveaway.
Conveyor Belt Scales: Integrating with dynamic weighing systems to calculate total mass flow rates of raw bulk materials.
Truck Scale Interfacing: Connecting factory platform scales directly into the plant-wide data logging system for tracking inbound and outbound shipping weights.
