1SDA014217R0001 ABB Bailey

Product Dimensions：

The 1SDA014217R0001 terminal set belongs to the legacy Isomax family of circuit breakers, which was a cornerstone of ABB's low-voltage power distribution portfolio. This specific accessory consists of extended front terminals designed to accept flat copper bars or specialized flat flexible cables rather than standard round stranded wire. This terminal arrangement allows for a higher surface area of contact, reducing electrical resistance and thermal buildup at the connection point. It mounts directly onto the front power ports of a 3-pole or 4-pole Isomax S3 circuit breaker, converting the standard connection style to a flat terminal configuration.

Product Parameters

• Product ID: 1SDA014217R0001

• EAN/Barcode: 8015644142179

• Accessory Type: Front terminals for flat cables (F Terminals)

• Compatible Circuit Breaker Series: ABB Isomax S3

• Number of Poles: Configured as a set suitable for 3-pole or 4-pole breaker frames depending on application layout

• Material Composition: High-conductivity tinned copper alloy for optimal current transfer and oxidation resistance

• Current Rating Compatibility: Matches the frame rating of the Isomax S3 breaker, typically up to $160 \text{ A}$ or $250 \text{ A}$ depending on the specific breaker configuration

• RoHS Status: Manufactured in accordance with relevant European environmental and material safety standards

Product Advantages

A key advantage of the 1SDA014217R0001 is its Enhanced Space Optimization. Flat flexible busbars or flat cables have a tighter bending radius than thick round cables, allowing panels to be designed with shallower depths. The Lower Thermal Footprint is another distinct benefit; the flat profile provides excellent heat dissipation compared to compacted round wires, reducing the risk of localized hotspots within the switchboard.

The Installation Efficiency is greatly improved because it eliminates the need for complex cable lug crimping tools; the flat bars or cables slide directly onto the flat terminal surface and are bolted securely. Additionally, the Corrosion Protection offered by the high-quality tin plating ensures long-term electrical conductivity even in humid or chemically aggressive industrial environments.

Important Considerations and Precautions

When installing the 1SDA014217R0001, observing Strict Tightening Torque is essential. Under-tightening the bolts will create high contact resistance, leading to thermal runaway and potential fire hazards, while over-tightening can strip the threads or deform the terminal block. Because this accessory is used in high-power distribution circuits, Complete Power Isolation must be verified before attempting installation or maintenance.

Technicians must maintain proper Phase-to-Phase Clearance when routing flat bars to prevent short-circuiting; using the phase barriers provided with the Isomax breaker housing is highly recommended. Furthermore, users should note that the Isomax series is a Legacy Platform that has been largely superseded by the newer Tmax and Tmax XT series. When managing long-term inventory or engineering new panels, verification of parts availability is critical, and migration plans to newer ABB platforms should be considered.

Product Applications

The 1SDA014217R0001 is predominantly used in industrial power distribution panels and motor control centers where space is limited and reliable power delivery is required.

• Main Distribution Boards: Connecting incoming power lines or busway systems to Isomax S3 feeder breakers within compact commercial or industrial switchgear.

• Motor Control Centers (MCCs): Supplying power to heavy-duty motor starters where flat flexible cabling is preferred for handling vibration.

• Renewable Energy Sub-panels: Interfacing inverter outputs into a centralized collection panel where flat copper busbars are utilized for efficiency.

• Marine and Offshore Switchboards: Used in shipboard electrical panels where space constraints require tight cable bends and high resistance to salt-induced oxidation.

• OEM Machinery Manufacturing: Integrated directly into the localized control cabinets of large industrial machines, such as injection molders or heavy presses, to simplify internal power distribution.
